Omada SG2210MP – 10-Port Gigabit Smart Switch with 8-Port PoE+

The Omada SG2210MP is a reliable and feature-rich Gigabit smart switch designed for small to medium business networks. It offers 8× Gigabit PoE+ RJ45 ports and 2× Gigabit SFP slots, delivering a total PoE budget of 150 W with up to 30 W per port. The switch supports both centralized cloud management via the Omada app and flexible standalone management, making it ideal for scalable and efficient network deployments.

**Hardware & Design**
- 8× 10/100/1000 Mbps RJ45 PoE+ ports with auto-negotiation and auto MDI/MDIX
- 2× 100/1000 Mbps SFP uplink slots
- One cooling fan with durable metal casing
- Physical security lock for added protection
- Rackmount or desktop installation
- Power supply: 100–240 V AC, 50/60 Hz
- Dimensions: 11.6 × 7.1 × 1.7 in (294 × 180 × 44 mm)

**Power & Efficiency**
- PoE standards: IEEE 802.3af/at compliant
- Total PoE power budget: 150 W
- Maximum power consumption: 174.2 W (with full PoE load)
- Heat dissipation: 594.46 BTU/hr

**Performance**
- Switching capacity: 20 Gbps
- Packet forwarding rate: 14.9 Mpps
- MAC address table: 8K entries
- Packet buffer memory: 4.1 Mbit
- Jumbo frame support: up to 9 KB

**Layer 2 & Layer 2+ Features**
- 16 IP interfaces with IPv4/IPv6 support
- Static routing: up to 32 IPv4/IPv6 routes
- DHCP server and relay (interface, VLAN, and L2 relay)
- Static, proxy, and gratuitous ARP
- Link aggregation, spanning tree protocol, and loopback detection
- Port mirroring, DLDP, and LLDP / LLDP-MED
- Flow control (IEEE 802.3x)

**Multicast & VLAN**
- Supports 511 IPv4/IPv6 multicast groups
- IGMP Snooping, MVR, multicast filtering
- Limited IP multicast profiles
- Up to 4K VLAN groups
- 802.1Q tag VLAN, MAC VLAN, protocol VLAN, GVRP, and voice VLAN

**Quality of Service (QoS)**
- 802.1p CoS and DSCP priority
- 8 priority queues
- Scheduling modes: SP and WRR
- Queue weight configuration
- Port and flow-based bandwidth control
- Broadcast, multicast, and unknown-unicast storm control

**Security & Access Control**
- IP-MAC-Port binding and AAA
- 802.1X authentication (port-based and MAC-based)
- Guest VLAN, MAB, and RADIUS authentication
- DHCP snooping (IPv4 & IPv6), ARP inspection, and ND detection
- IP and IPv6 source guard
- DoS defense and port security (up to 64 MAC addresses per port)
- ACL support with up to 230 entries, including time-based, MAC, IP, and IPv6 ACLs
- Secure management via HTTPS (SSL/TLS) and SSH

**IPv6 & Management**
- Dual-stack IPv4/IPv6 support
- IPv6 static routing, ACL, MLD snooping, and ND
- IPv6 applications: DHCPv6, Ping6, Tracert6, SNMP, SSH, HTTPS, and TFTP
- Centralized management using Omada Cloud-Based, Hardware, or Software Controller
- Zero-Touch Provisioning support
- Web GUI, CLI, SNMP v1/v2c/v3, RMON, SDM templates
- Dual image and dual configuration for reliability
- CPU monitoring, cable diagnostics, EEE, SNTP, and system logs

**Package & Environment**
- Package includes: SG2210MP switch, power cord, installation guide, rackmount kit, and rubber feet
- Certifications: CE, FCC, RoHS
- Operating temperature: 0–50 ℃
- Storage temperature: -40–70 ℃
- Operating humidity: 10–90% RH (non-condensing)

The Omada SG2210MP delivers dependable PoE power, advanced Layer 2+ features, and flexible management options, making it an excellent choice for IP cameras, wireless access points,
