Omada EAP230-Wall AC1200 Wireless MU-MIMO Gigabit Wall-Plate Access Point - 18 Months Official Warranty
$0.00
Skip to product information
Omada EAP230-Wall AC1200 Wireless MU-MIMO Gigabit Wall-Plate Access Point - 18 Months Official Warranty
$0.00
| EAP230-Wall AC1200 Wall-Plate Access Point | Rephrased Version |
|---|---|
| Simultaneous 300 Mbps on 2.4 GHz and 867 Mbps on 5 GHz with MU-MIMO. | Dual-band WiFi delivers up to 1,167 Mbps combined speed with MU-MIMO for improved efficiency. |
| 2 Gigabit Ethernet ports (1 uplink + 1 downlink). | Comes with one uplink and one downlink Gigabit port for stable wired connections. |
| Integrated with Omada SDN for ZTP, cloud management, and smart monitoring. | Fully compatible with Omada SDN, enabling zero-touch setup, cloud access, and advanced monitoring. |
| Manage via cloud or Omada app for convenience. | Easily controlled from anywhere through the Omada app or cloud dashboard. |
| Designed for rooms in hotels, offices, and dormitories. | Ideal for multi-room environments requiring reliable, isolated WiFi for each room. |
| Slim 11 mm profile matching standard wall switch size. | Ultra-thin, switch-style faceplate blends naturally into any interior. |
| Easy installation with 86 mm/EU box compatibility and PoE support. | Installs quickly on standard wall boxes and supports 802.3af/at PoE for flexible deployment. |
| Guest network with SMS, voucher login, and strong wireless security. | Supports secure guest access with multiple authentication and business-grade WiFi protections. |
| Uplink: 1× Gigabit port. Downlink: 1× Gigabit port. | Offers dedicated uplink and downlink Gigabit connectivity for reliable wired devices. |
| LED/Wi-Fi button and RESET button. | Includes WiFi/LED toggle and reset controls for quick adjustments. |
| Powered by 802.3af/at PoE, max consumption 7W. | Runs on PoE with low energy usage for cost-efficient operation. |
| Dimensions: 86.8 × 86.8 × 30.2 mm. | Compact square design suitable for wall mounting. |
| 2 dual-band antennas: 2.4 GHz (2× 4 dBi), 5 GHz (2× 3.6 dBi). | Built with dual-band internal antennas for balanced coverage. |
| Coverage: 25㎡ (300 ft²), supports 200+ clients. | Delivers room-wide WiFi and handles over 200 connected devices. |
| Supports 802.11n/g/b/ac, dual-band operation. | Works on both 2.4 GHz and 5 GHz with AC1200 capability. |
| WiFi functions: 16 SSIDs, channel assignment, power control, QoS, roaming, load balance, rate limit, scheduling, MU-MIMO, steering, beamforming. | Equipped with advanced wireless tools for stability, performance tuning, and multi-SSID setups. |
| Security: Captive portal, access control, MAC filtering, client isolation, VLANs, rogue AP detection, 802.1X, WPA/WPA2. | Strong enterprise-level protections including VLAN tagging, secure authentication, and intrusion alerts. |
| Supports Omada App, cloud access, SNMP, SSH, HTTP/HTTPS, L3, multi-site management. | Complete management suite with remote access, SNMP, SSH, L3 features, and central control. |
| Certifications: CE, RoHS. | Compliant with international safety and environmental standards. |
| Package: Access point, guide, screws. | Includes all mounting hardware and quick start instructions. |
| Operating temp: 0–40°C. Storage: -40–70°C. | Designed to operate safely in typical indoor temperature and humidity ranges. |
