Omada EAP225 AC1350 Wireless MU-MIMO Gigabit Ceiling Mount Access Point - 18 Months Official Warranty

AC1350 Wireless MU-MIMO Gigabit Ceiling Mount Access Point
Delivers reliable dual-band Wi-Fi with combined speeds of up to 1317 Mbps, offering 450 Mbps on the 2.4 GHz band and 867 Mbps on the 5 GHz band. Fully integrated into the Omada SDN platform, it supports Zero-Touch Provisioning, centralized cloud management, and intelligent network monitoring. Seamless roaming ensures uninterrupted voice calls and video streaming as users move throughout the coverage area. Flexible installation is supported through both standard 802.3af/at PoE and 48V passive PoE, with a PoE adapter included. Advanced wireless technologies such as MU-MIMO, band steering, airtime fairness, and beamforming enhance performance in busy environments, while a secure guest network with multiple authentication options provides strong access control and wireless protection.

Hardware Features:
- 1× Gigabit Ethernet (RJ-45) port supporting 802.3af/at PoE and passive PoE
- Physical security lock
- Reset button
- Power supply via 802.3af/at PoE or 48V passive PoE (adapter included)
- Maximum power consumption: 9.7 W (EU), 12.1 W (US)
- Dimensions: 8.1 × 7.1 × 1.5 in (205.5 × 181.5 × 37.1 mm)
- Internal omni antennas: 2.4 GHz 4 dBi, 5 GHz 5 dBi
- Ceiling and wall mounting supported (kits included)

Wireless Features:
- Coverage area: up to 115 m² (1250 ft²)
- Supports 220+ concurrent clients
- Wireless standards: IEEE 802.11ac/n/g/b/a
- Dual-band frequency: 2.4 GHz and 5 GHz
- Wireless speeds: up to 867 Mbps on 5 GHz and 450 Mbps on 2.4 GHz
- Wireless capabilities include up to 15 SSIDs, radio enable/disable, automatic channel selection, transmit power control, QoS (WMM), seamless roaming (802.11k/v/r), Omada Mesh, band steering, load balancing, MU-MIMO, airtime fairness, beamforming, rate limiting, scheduled reboot, wireless scheduling, and detailed wireless statistics per SSID, access point, and client

Wireless Security:
- Captive portal authentication
- Access control and MAC address filtering
- Client isolation
- SSID to VLAN mapping
- Rogue access point detection
- 802.1X authentication support

Transmission Power:
- CE: ≤20 dBm (2.4 GHz EIRP), ≤23 dBm (5 GHz EIRP)
- FCC: ≤24 dBm (2.4 GHz), ≤22 dBm (5 GHz)

Management Features:
- Omada app support
- Centralized management via Omada cloud-based, hardware, or software controllers
- Cloud access through Omada controller
- Email alerts and LED control
- Management MAC access control
- SNMP v1 and v2c
- Local and remote syslog support
- SSH access
- Web-based management via HTTP/HTTPS
- Layer 3 management, multi-site management, and management VLAN
- Zero-Touch Provisioning supported via Omada cloud controller

Other Details:
- Certifications: CE, FCC, RoHS
- Package includes AC1350 EAP225 access point, passive PoE adapter, power cord, mounting kits, and installation guide
- Compatible operating systems: Windows XP through Windows 11, Linux
- Operating temperature: 0–40 ℃; storage temperature: -40–70 ℃
- Operating humidity: 10–90% RH non-condensing; storage humidity: 5–90% RH
