MT-SW108D
8 Port 10/100Mbps Switch Lite Series
Description
The MT-SW108D 8-port 10/100Mbps Fast Ethernet Switch provides 8 10/100Mbps Auto Negotiation RJ45 ports. All ports support Auto MDI/MDIX function, eliminating the need for crossover cables or Uplink ports. The Switch is Plug-and-Play and each port can be used as general ports or Uplink ports and can be simply plugged into a server, a hub or a switch, using straight cable or crossover cable. The MT-Link MT-SW108D 8-port 10/100M Fast Ethernet Switch provides you with a low-cost, easy-to-use, high-performance, seamless and standard upgrade to improve your old network to a 100Mbps network. It will boost your network performance up to full duplex data transfer. Its wire-speed switching that forwards packets can be as fast as the speed that your network delivers those packets to them.
Overview
The MT-SW108D 8-port 10/100Mbps Fast Ethernet Switch provides 8 10/100Mbps Auto Negotiation RJ45 ports. All ports support Auto MDI/MDIX function, eliminating the need for crossover cables or Uplink ports. The Switch is Plug-and-Play and each port can be used as general ports or Uplink ports and can be simply plugged into a server, a hub or a switch, using straight cable or crossover cable. The MT-Link MT-SW108D 8-port 10/100M Fast Ethernet Switch provides you with a low-cost, easy-to-use, high-performance, seamless and standard upgrade to improve your old network to a 100Mbps network. It will boost your network performance up to full duplex data transfer. Its wire-speed switching that forwards packets can be as fast as the speed that your network delivers those packets to them.
Features
- Supports IEEE 802.3x flow control for Full Duplex mode and backpressure for half-duplex mode.
- Supports MAC address auto learning and auto-aging.
- LED indicators for monitoring power, link, activity.
- Plastic case, desktop or wall mounting design.
- External Power Adapter supply.
Standards and Protocols IEEE802.3, 802.3u, 802.3x, CSMA/CD, TCP/IP Basic Function Wire-speed Performance
MAC Address Auto-Learning and Auto-aging
IEEE802.3x flow control for Full-Duplex Mode and
backpressure for Half-Duplex ModeBackbound Bandwidth 1.6Gbps MAC Address Table 1k Forwarding Rate 10BASE-T: 14880pps/port
100BASE-TX: 148800pps/portTransmission Method Store-and-Forward Ports 8 10/100Mbps Auto-Negotiation RJ45 ports (Auto MDI/MDIX) Network Media 10Base-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ù STP (maximum 100m)
100Base-Tx: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ù STP (maximum 100m)LED Indicators 1Power, Link/Act (1, 2, 3, 4, 5) Safety & Emission FCC, CE Dimensions (W*D*H) 5.5*3.4*1.1 in. (140*87*27.5 mm) Environment Operating Temperature: 0C-40C (32F-104F)
Storage Temperature: -40C-70C (-40F-158F)
Operating Humidity: 10%-90% non-condensing
Storage Humidity: 5%-90% non-condensingPower External Power Adapter
